TOFD Caliper

A compact, lightweight, user friendly single-axis scanner, the TOFD Caliper is the perfect tool to provide a quick and simple, manual weld inspection. It is very easy to setup with the probe separation being adjusted from a single thumb screw.



The TOFD Caliper operates in any orientation on surfaces from 3” NPS up to flat plate and is suitable for inspecting welds on pipework, pressure vessels, storage tanks and structural components.



Compatible with our full range of TOFD transducers and wedges, the TOFD Caliper frame allows the wedges to be easily clipped into the arms so that interchanging a wedge takes seconds.



TOFD Wedges can be plastic, brass, or stainless steel and are available at 45°, 60° and 70° as standard. The TOFD Caliper includes a high resolution, waterproof wheel encoder that can operate with any manufacturer’s instrumentation.



Often used as the ideal training tool, the TOFD Caliper is suitable for use by inspectors of any level due to its simplicity, reliability and quick wedge interchange.

Interested with This Product?

Standard Kit

Standard Kit for Caliper

  • Caliper Frame
  • Spring loaded waterproof wheel encoder with 5m cable
  • Couplant tube and ‘Y’ connectors
  • Durable carrying case

Features

Features for Caliper

  • Spring loaded waterproof wheel encoder. IP68 rated
  • Encoder Resolution: 65.6 steps/mm
  • Spring-loaded tool posts can be locked-off the scan surface
  • Brake system locks scanner in position for single axis inspections
  • Thumbscrews eliminate the need for any tools
  • Four magnetic wheels provide firm attachment, stability and smooth rolling action on ferritic materials
  • Ergonomic cable management
  • Frame Construction: Light aluminium frame with operating handle
  • Scanner Dimensions (mm): L 385 x H 95 x W 230
  • Termination: Compatible with all acquisition units
  • Range: 3” pipe (Ø88.9mm) up to flat plate

Benefits

Benefits for Caliper

  • ‘Plug in and go’ design
  • Fast, simple weld inspections with easily adjustable PCS
  • Operates on pipe diameters as small as 75mm
  • Compact ‘pocket-sized’ durable tool
  • Cost effective option for TOFD weld inspection
  • Ideal for position related A, B, D and echo dynamic scan data collection
  • Applicable to pipework, pressure vessels storage tanks and structural components
